LED line PRIME Panel Backlit 34W 4000K 4760lm UGR<19 620×620 DALI
Kod produktu 205857
LED line PRIME Backlit panel with 34W DALI function, provides optimal illumination in 4000K color temperature. The panel generates an impressive light output of 4760 lumens, making it ideal for a variety of applications.
An extremely important aspect of this panel is its low UGR<19. This means that it is a product with reduced glare, which affects the comfort of work and the overall quality of lighting in a room. Designed in a dimension specifically for the German market - 62x62cm, the panel is easy to install and fits perfectly into most office, retail or commercial spaces.
Another advantage of the luminaires is their good technical parameters. The panel is made of high-quality materials and and equipped with a power supply from the renowned Lifud brand.
The Backlit LED line PRIME panel is an ideal solution for the German market, where energy-saving and efficient light sources are needed for lighting projects. Its high lighting quality and low glare make it an excellent choice for office, retail, educational spaces and other places where comfort and lighting quality play a key role.
The luminaire has a backlit design, which means placing the LEDs on the back of the body to ensure high and uniform light output.
Equipped with a yellow free type diffuser, it does not yellow, and the micro-prismatic texture provides high light transmittance while reducing glare (UGR<19 rating), which is beneficial for user comfort.
A solid power supply Lifud brand is a guarantee of trouble-free operation, but also a long life of the luminaire.
The luminaire provides high performance: an impressive luminous flux of 4760 lm and an efficiency of 140 lm/W. The luminaires are available with a 5-year warranty, ensuring that your investment in the panel is covered by solid manufacturer support and demonstrating confidence in the durability and reliability of the luminaires offered.
In addition, the Panel has a DALI function. The use of this intelligent LED lighting control is one of the ways to reduce the cost of business. Through this solution, you can save even more than 90% of the costs associated with lighting. Thanks to the DALI system, it is possible, for example, to reduce the intensity of light in some work areas that are not currently in use, or have sufficient daylight, which allows you to reduce the cost of maintaining the facility.
Backlit LED line PRIME panel is an excellent solution also because of the possibility of multiple mounting options. It allows flush mounting in modular suspended ceilings. It will also work well in cardboard/gypsum ceilings, using special brackets. Surface mounting is possible with a frame.
The luminaire is ENEC certified, confirming its high quality and compliance with European safety standards.
Parametry techniczne
| Parametr | Wartość |
|---|---|
| Energy efficiency class 2019/2015 | C |
| Colour of the light | White |
| Colour consistency in McAdam ellipses | ≤6 |
| Luminous flux | 4760 |
| Luminous efficacy | 140 |
| IP protection rating | IP20 |
| Warranty (years) | 5 |
| Contain icon | NonRepl1+NonRepl2 |
| Survival factor | 0.9 |
| Flicker Free | YES |
| UGR rating | UGR<19 |
| Current | 0,164 |
| Frequency of the supply voltage | 50/60Hz |
| Colour rendering index Ra | 80 |
| Colour | White |
| The lumen maintenance factor | 96 |
| Beam angle | 90 |
| Material (cover) | polystyrene |
| Material (housing) | aluminum |
| LED type | SMD LED 2835 |
| LED quantity | 64 |
| Power Factor | 0,9 |
| Number of on/off cycles | 50000 |
| Colour consistency in McAdam ellipses | ≤6 |
| Ambient temperature suitable for operation | -20÷40 |
| For indoor use | Inside |
| IEC protection class | II |
| IK protection rating | 02 |
| Lamp's warm-up time to 60% | 1 s |
| Height | 30 |
| GPC classification | 10005639 - Lighting - permanently mounted |
| GS1 unit | szt |
| Width | 35 |
| Height | 640 |
| Length | 630 |
| Weight | 1,97 |
| Number of pieces/tape in meters pack zb | 5 |
| Width | 200 |
| Height of collective packaging | 655 |
| Length | 645 |
| Weight | 12,8 |
| Volume | 0,085 |
| Quantity collective euro pallet | 60 |
| Pallet height | 1880 |
| Quantity in 1 layer | 25 |
