Waterproof fixture RANGER 10-40W 4000K 7200lm 120cm IP66 PRIME
Product code 210189
RANGER is a series of modern, hermetic LED luminaires designed for demanding industrial and commercial environments. They are characterized by high luminous efficacy of 150-180 lm/W and an impressive service life of 100,000 hours. Thanks to a wide power range from 10 to 80 W and the availability of models with a length of 120 and 150 cm, these products allow for precise adjustment to the individual needs of the user.
The RANGER series includes versions with a light color of 4000K, as well as models with adjustable color temperature in the range of 3000K, 4000K and 5000K. The luminaires offer a luminous flux from 7200 to 14400 lm and a light distribution angle of 120°, which guarantees uniform lighting of large surfaces. Thanks to the high degree of tightness IP66, the products are resistant to dust and water, making them an excellent choice for work in difficult conditions. The luminaires can operate in a wide temperature range from -25°C to +45°C and offer the possibility of linking, which makes it easier to create light lines.
Available models include variants such as 10-40 W, 120 cm long, with a light color of 4000K and a luminous flux of 7200 lm, or 60-80 W, 150 cm long, with a color of 4000K and a flux of 14400 lm. All products in the series are covered by a five-year warranty, which is a confirmation of their reliability and high quality.
RANGER is a universal solution that works perfectly in warehouses, production halls, and outdoor spaces. It combines efficiency, durability and aesthetics, offering lighting tailored to the most demanding applications.
RANGER is a modern, hermetic LED luminaire designed for demanding industrial and commercial environments. They are characterized by high luminous efficacy of 150-180 lm/W, a service life of 100,000 hours and a wide power range of 10-80 W. They are available in lengths of 120 and 150 cm and offer a light color of 4000K or adjustment of 3000K-5000K.
The luminaires provide a luminous flux of 7200-14400 lm, a beam angle of 120° and a degree of tightness of IP66, which guarantees resistance to dust and water. They can operate in temperatures from -25°C to +45°C.
The 10-40 W models with a length of 120 cm and 60-80 W with a length of 150 cm are covered by a five-year warranty, which confirms their reliability. The RANGER series is a universal and durable solution ideal for warehouses, production halls and outdoor spaces.
Technical parameters
Parametr | Wartość |
---|---|
Energy efficiency class 2019/2015 | C |
Colour of the light | White |
Colour consistency in McAdam ellipses | ≤6 |
Luminous flux | 7200lm |
Luminous efficacy | 180lm/W |
Standby power Psb | 10-40W |
Controller-Symbol | 180 |
IP protection rating | IP66 |
Warranty (years) | 5 |
Survival factor | 0.9 |
Weight | 1400g |
Flicker Free | YES |
Current | 0,193 |
Frequency of the supply voltage | 50/60Hz |
Colour rendering index Ra | 80 |
Colour | 220-240 VAC |
The lumen maintenance factor | 96% |
Beam angle | 120° |
Material (cover) | polycarbonate |
Material (housing) | Polycarbonate |
LED type | SMD2835 |
LED quantity | 276 |
Power Factor | 0,9 |
Number of on/off cycles | 50000 |
Colour consistency in McAdam ellipses | ≤6 |
Ambient temperature suitable for operation | -25÷45°C |
For indoor and outdoor use | YES |
IEC protection class | I |
IK protection rating | 10 |
Full box quantity | 12pc |
Lamp's warm-up time to 60% | 1 |
Length | 1210mm |
Width | 79mm |
Height | 68mm |
Product weight with packaging | 1562g |
Displacement factor Df | 2024-11-08 18:24:10 |
GPC classification | 10005639 - Lighting - permanently mounted |
GS1 unit | szt |
Number of pieces/tape in meters pack zb | 12 |
